Parallel Shaft Gearmotors

Get a Price/Quote

MOQ : 1 Piece

Parallel Shaft Gearmotors Specification

Starting Type
Direct-On-Line (DOL)

Cooling Method
Fan Cooled

Rated Voltage
415V Three Phase

Ambient Temperature
-20C to 50C

Horse Power
0.2 HP to 20 HP

Rated Frequency
50 Hz / 60 Hz

Bearing Type
Heavy Duty Ball Bearing

Torque
Up to 3000 Nm

Sealed Type
Oil Sealed

Features
High Efficiency, Reliable Performance, Compact Design

Voltage
220V / 380V / 415V

Efficacy
IE2 / IE3 (as per requirement)

Poles Number
2, 4, 6, 8 poles

Noise Level
< 70 dB

Power Rating
As per specification

Standard
IS, IEC certified

Motor Type
Induction / Squirrel Cage / Foot Mount

Current Type
AC

Product Type
Parallel Shaft Gearmotor

Output Power
Up to 15 kW

Frequency (MHz)
50/60 Hz

Protect Feature
TEFC (Totally Enclosed Fan Cooled) / IP55

Phase
Three Phase / Single Phase

Speed
Up to 2800 RPM

Power
0.18 kW to 15 kW

Color
Blue / Customized

Dimension (L*W*H)
As per model selection

Weight
Varies as per model

Shaft Diameter
Customizable as per model

Mounting Type
Flange / Foot Mounted

IP Rating
IP54 / IP55

Duty Cycle
S1 (Continuous)

Vibration Level
Low Vibration

Gear Ratio
Up to 200:1

Frame Material
Cast Iron/Aluminum

Output Shaft Position
Parallel to Motor Shaft

Insulation Class
F/H (optional)

Input Type
Motorized / Free Input

Overload Capacity
Up to 200%

Lubrication Type
Grease/Oil filled

Parallel Shaft Gearmotors Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash in Advance (CID)

Supply Ability
100 Pieces Per Month

Delivery Time
Week

Main Domestic Market
All India

Parallel Shaft Gearmotors About

Parallel shaft gearmotors typically consist of two or more sets of gears, with each set mounted on a separate parallel shaft. The gears in the gearbox transmit power and torque from the input shaft to the output shaft through meshing teeth.

Engineered for Reliability and Performance

Our parallel shaft gearmotors combine high-grade helical gears with precision construction in robust cast iron or lightweight aluminum frames. Designed for minimal vibration and less than 70 dB noise, they deliver exceptional service in demanding, continuous-duty applications. With advanced lubrication (grease/oil filled), heavy-duty ball bearings, and customizable shaft diameters, they ensure longevity and consistent performance.

Versatile Mounting and Operating Flexibility

Available in flange or foot-mounted designs, these gearmotors adapt effortlessly to a range of systems. Whether you require a three-phase or single-phase input, select models offer flexible voltage, pole, and speed configurations up to 2800 RPM. Their compact design and customizable dimensions facilitate integration into new or existing setups.

FAQ's of Parallel Shaft Gearmotors:

Q: How do I choose the right gear ratio and mounting type for my application?

A: To select the suitable gear ratio and mounting type, assess your load requirements, desired output speed, and installation constraints. With ratios up to 200:1 and available flange or foot mounts, these gearmotors cater to diverse situations. Consulting technical datasheets or contacting our support team helps tailor the solution to your specific setup.

Q: What are the advantages of using a parallel shaft gearmotor with helical gears?

A: Helical gears provide smoother, quieter operation compared to spur gears, resulting in less vibration and noise (<70 dB). Coupled with precision machining and robust materials, these units deliver high efficiency, increased torque output up to 3000 Nm, and reliable continuous-duty performance for industrial environments.

Q: Where can I install these gearmotors, and what environmental conditions are supported?

A: These gearmotors are engineered for versatile industrial placements, both indoors and outdoors, where temperatures range from -20C to 50C. Their TEFC/IP55 enclosures ensure protection against dust and water ingress, making them suitable for demanding or harsh operating environments.

Q: What is the process for lubrication and maintenance?

A: Units are supplied either grease or oil-filled and equipped with heavy-duty ball bearings, reducing frequent maintenance. Regular checks of lubricant levels and condition are recommended for optimal longevity. Maintenance guidelines and schedules are provided in the product manual.

Q: What are the main benefits of choosing this gearmotor over other types?

A: Key benefits include high operational efficiency (IE2/IE3), compact design for easier integration, customizable specifications, reliable performance under overload (up to 200% capacity), and compliance with IS/IEC standards. The range of configurations suits a variety of industrial sectors, ensuring users get the best fit for their operational needs.

Q: When does the warranty apply, and what does it cover?

A: A 1-year warranty from the date of purchase covers manufacturing defects and issues arising from normal operation, provided maintenance recommendations are followed. It ensures users have peace of mind regarding build quality and reliability.
